600 WOG “Full Port” Brass Ball Valves

Full Port Brass Ball Valves are two-piece construction with a chrome plated brass ball,
blowout-proof stem, PTFE seats and double ‘O’ ring stem seal. Quick quarter-turn for easy
operation. For use in plumbing and light industry applications. Standard NPT end connection.
Working Pressure Test Pressure.
600 psi W.O.G. Shell ............. 900 psi. hydrostatic
150 psi A 300° F Seat .............. 80 psi. air
Dimensions inch
Size 1/4 3/8 1/2 3/4 1 1-1/4
Bore 0.39 0.39 0.59 0.79 0.98 1.26
L (IPS) 1.57 1.61 1.93 2.20 2.56 2.99
L (C x C) 1.73 1.81 2.13 2.87 3.47 3.94
H 1.42 1.42 1.54 1.73 1.93 2.17
D 3.15 3.15 3.15 5.12 5.12 5.12
